Drawing Architecture and the Urban

Sam Jacoby (Autor)

Buch | Softcover

336 Seiten

2016
John Wiley & Sons Inc (Verlag)
978-1-118-87940-5 (ISBN)

Artikel merken

Drawing is an important means to analyse information and develop rigorous arguments both conceptually and visually. Going beyond the how-to drawing manual, this book provides an instrumental approach to drawing, especially computer-generated drawings; it outlines how drawings should be used to convey clear and analytical information in the process of design, as well as the communication and discussion of a project. In depth examples are provided how to communicate effectively. The final section demonstrates how to transform case-studies, directly connecting an analytical approach with the design process.

Sam Jacoby (AA Dip, Dr.-Ing, ARB, RIBA) is a chartered architect and educator with eleven years of experience teaching design studios at undergraduate and graduate level. He is Director of the MPhil in Architecture and Urban Design (Projective Cities) programme at the Architectural Association School of Architecture and Teaching Fellow on the MArch Urban Design, Bartlett School of Architecture, University College London (UCL). He has previously taught at the University of Nottingham and worked for various architectural and planning offices in the UK, USA and Malaysia.

INTRODUCTION

Description, Analysis and Transformation: Drawing as Diagram

CHAPTER 1: CONVENTIONS

1 Point, Line, Plane and Volume

2 Plan Conventions

2.1 Orthographic Projections (Elevation)

2.2 Cut-away Views (Plan and Section)

2.3 Paraline Drawings

2.4 Perspective Drawings

3 Graphic Conventions

3.1 Line Weight, Style and Type

3.2 Hatching, Texture, Material and Shading

3.3 Colour

3.4 Drawing Scale and Paper Size

3.5 Annotation and Dimensioning

CHAPTER 2: ARCHITECTURE

1 Description

1.1 Context: Location Plan and Site Section

1.2 Building: Plan, Elevation and Section

1.3 Building: Axonometric and Perspective

2 Analysis

2.1 Context: Figure-Ground Plan

2.2 Context: Orientation

2.3 Building: Massing

2.4 Building: Structural Organisation

2.5 Building: Programme

2.6 Building: Circulation-to-Use

2.7 Building: Part-to-Whole

2.8 Building: Repetitive-to-Unique

2.9 Building: Geometrical Order

2.10 Building: Parti

3 Comparison

3.1 Free Plan vs Raumplan

3.2 Deconstruction of Whole to Parts

3.3 Vertical vs Horizontal

3.4 Sectional Organisation

3.5 Landscape and Landform

3.6 Modularity

4 Comparative Matrices

4.1 Massing

4.2 Conceptual Organisation

4.3 Disposition

4.4 Distribution

4.5 Circulation

4.6 Difference

4.7 Growth

CHAPTER 3: THE URBAN

1 Description

1.1 Urban Plan

1.2 Land Use

1.3 Density

1.4 Circulation (Transport)

1.5 Open Spaces

1.6 Infrastructures

2 Analysis

2.1 Figure-Ground Plan

2.2 Hierarchies and Organisation

2.3 Part-to-Whole and Repetitive-to-Unique

2.4 Built Environment

2.5 Phasing

3 Comparison

3.1 Block

3.2 Enclave

3.3 Ground

3.4 Infrastructure

4 Comparative Matrices

4.1 Size

4.2 Distribution

4.3 Hierarchy and Layering

4.4 Difference

4.5 Growth

4.6 Architectural Types and Urban Morphology

CHAPTER 4: TRANSFORMATION

1 Typological Transformation

1.1 Timeline

1.2 Comparative Matrix

1.3 Comparative Diagrams

1.4 Typological Transformation Diagrams

1.5 Transformative Matrix

2 Design Examples

2.1 Tokyo Podium by Sakiko Goto

2.2 The City Campus by Marcin Ganczarski

2.3 The Chinese Unit by Yuwei Wang

2.4 Cité Housing by Alvaro Arancibia Tagle

Drawing Acknowledgements and References

Erscheint lt. Verlag	25.4.2016
Verlagsort	New York
Sprache	englisch
Maße	216 x 282 mm
Gewicht	1315 g
Themenwelt	Sozialwissenschaften ► Soziologie
Themenwelt	Technik ► Architektur
ISBN-10	1-118-87940-6 / 1118879406
ISBN-13	978-1-118-87940-5 / 9781118879405
Zustand	Neuware
