Mastering Circuit Analysis

Analyzing DC, AC, and Magnetic Circuits

Hubert Henry Ward (Autor)

Buch | Softcover

619 Seiten

2025
Apress (Verlag)
979-8-8688-1831-8 (ISBN)

Artikel merken

This book is your essential guide to mastering the fundamentals of electrical analysis. Starting with direct current (DC), it explores batteries, current, voltage, and key concepts like Ohm’s Law and Kirchhoff’s Laws for circuit analysis. Progressing to advanced topics, you'll learn about mesh analysis, superposition, Thevenin’s and Norton’s Theorems, and transient analysis, including time constants and DC RL/RC circuits.

The journey continues with alternating current (AC), covering RMS values, phasors, complex numbers, and AC RLC circuits used in radio receivers. The final chapter dives into the world of magnets and magnetic circuits. Throughout, simulations using TINA 12 ECAD software demonstrate the accuracy of the methods discussed.

This book equips engineers with the essential knowledge and skills to excel in electrical analysis. By mastering these foundational topics, readers will build the confidence and expertise needed to achieve qualifications and design innovative systems with ease.

What You'll Learn

Understand DC fundamentals, including batteries, current flow, and voltage.
Analyze DC and AC circuits using Ohm’s Law, Kirchhoff’s Laws, and advanced methods like superposition.
Explore transient analysis with time constants and DC RL/RC circuits.
Master AC concepts such as RMS values, phasors, and AC RLC circuits.
Simulate and validate circuits using TINA 12 ECAD software.

Who is This Book For

Students on electrical engineering courses or hobbyists who wants to learn about DC and ac circuit theories.

Hubert Ward has been a college lecturer since 1993 and over 24 years experience teaching at the Higher National Certificate and The Higher Diploma in Electrical & Electronic Engineering. Hubert has also spent time as a consultant in embedded programming in assembler language and C and was the UK technical expert in Mechatronics where he trained the UK team for the Skills Olympics in Seoul 2001. Hubert Ward is also happily married to his wife Ann and with whom he has two wonderful children, Claire and Vincent.

Chapter One “Electrical Current”.- Chapter Two “The Fundamental Theories”.- Chapter Three “Analyzing Circuits with Multiple Sources”.- Chapter Four “DC RL Transient Analysis” .- Chapter Five “DC CR Transient Analysis” .- Chapter Six “The UK Mains Voltage”.- Chapter Seven “The Series and Parallel RLC Circuit” .- Chapter Eight “Analysis of ac Circuits”.- Chapter Nine “Analysis of Magnetic Circuits”.- Chapter TEN “Using TINA 12” .

Erscheinungsdatum	31.10.2025
Reihe/Serie	Maker Innovations Series
Zusatzinfo	266 Illustrations, black and white
Verlagsort	Berkley
Sprache	englisch
Maße	155 x 235 mm
Themenwelt	Informatik ► Weitere Themen ► Hardware
Themenwelt	Technik ► Elektrotechnik / Energietechnik
ISBN-13	979-8-8688-1831-8 / 9798868818318
Zustand	Neuware
