Inductively Coupled Coils Angle Encoders with Improved Performance and Linearity
Seiten
Although angle and position measurement is one of the seemingly simpler
disciplines in metrology, the known measurement procedures comprise
mathematical and physical challenges. In the case of inductive sensors, this is
usually due to the eddy currents used for measurement, which are difficult to
calculate analytically. For this reason, cumbersome FE simulations are generally
used to predict important parameters such as sensor accuracy.
This book presents an approach to drastically reduce such simulations and
behavior predictions that combines simplified simulation models with statistical
methods. As a result, mathematical models are generated, which can even replace
simulation completely. In addition, simple guidelines for the sensor design can
be derived from the models obtained.
The sensor accuracy is usually calculated as a deviation from a reference signal. It
shows characteristic orders in the harmonic analysis. For this inductive principle,
a fourth order is dominant within a signal period. With the method developed,
this order could be minimized by improving the coil geometry.
disciplines in metrology, the known measurement procedures comprise
mathematical and physical challenges. In the case of inductive sensors, this is
usually due to the eddy currents used for measurement, which are difficult to
calculate analytically. For this reason, cumbersome FE simulations are generally
used to predict important parameters such as sensor accuracy.
This book presents an approach to drastically reduce such simulations and
behavior predictions that combines simplified simulation models with statistical
methods. As a result, mathematical models are generated, which can even replace
simulation completely. In addition, simple guidelines for the sensor design can
be derived from the models obtained.
The sensor accuracy is usually calculated as a deviation from a reference signal. It
shows characteristic orders in the harmonic analysis. For this inductive principle,
a fourth order is dominant within a signal period. With the method developed,
this order could be minimized by improving the coil geometry.
| Erscheinungsdatum | 31.01.2025 |
|---|---|
| Reihe/Serie | Dresdner Beiträge zur Sensorik ; 93 |
| Verlagsort | Dresden |
| Sprache | englisch |
| Maße | 158 x 225 mm |
| Themenwelt | Technik ► Elektrotechnik / Energietechnik |
| Schlagworte | Coils • Improvement • inductive • Performance |
| ISBN-10 | 3-95908-751-9 / 3959087519 |
| ISBN-13 | 978-3-95908-751-3 / 9783959087513 |
| Zustand | Neuware |
| Informationen gemäß Produktsicherheitsverordnung (GPSR) | |
| Haben Sie eine Frage zum Produkt? |
