Integrated Sub-Millimeter-Wave High-Power Amplifiers in Advanced InGaAs-Channel HEMT Technology
Seiten
Highly broadband power amplifiers are a key building block of next generation high-capacity communication and high-resolution imaging solution at the lower THz frequency band around 300 GHz. This thesis describes the investigation and realization of such high-power amplifiers, implemented in an InGaAs mHEMT technology.
Driven by the large absolute bandwidths that are available at the sub-mm-wave frequency range around 300 GHz, wireless high-data-rate communication systems and high-resolution imaging applications are being extensively investigated in recent years. Due to their superior characteristics in terms of noise figure and cutoff frequencies, InGaAs-channel HEMT devices have proven to be a key technology to implement the required active front-end MMICs for these wireless THz systems, enabling ultra-high bandwidths and state-of-the-art noise performance. This work describes the modeling, design, and characterization of 300-GHz HEMT-based power amplifier cells and demonstrates the implementation of highly compact amplifier MMICs and broadband waveguide modules. These amplifiers are key components for the implementation of high-performance chipsets for wireless THz systems, providing high output power for the utilization of next-generation communication and imaging applications. A unique amplifier topology based on multi-finger cascode and common-source devices is developed and evaluated, demonstrating more than 20-mW measured output power at the sub-mm-wave frequency range around 300 GHz.
Driven by the large absolute bandwidths that are available at the sub-mm-wave frequency range around 300 GHz, wireless high-data-rate communication systems and high-resolution imaging applications are being extensively investigated in recent years. Due to their superior characteristics in terms of noise figure and cutoff frequencies, InGaAs-channel HEMT devices have proven to be a key technology to implement the required active front-end MMICs for these wireless THz systems, enabling ultra-high bandwidths and state-of-the-art noise performance. This work describes the modeling, design, and characterization of 300-GHz HEMT-based power amplifier cells and demonstrates the implementation of highly compact amplifier MMICs and broadband waveguide modules. These amplifiers are key components for the implementation of high-performance chipsets for wireless THz systems, providing high output power for the utilization of next-generation communication and imaging applications. A unique amplifier topology based on multi-finger cascode and common-source devices is developed and evaluated, demonstrating more than 20-mW measured output power at the sub-mm-wave frequency range around 300 GHz.
| Erscheinungsdatum | 14.12.2021 |
|---|---|
| Reihe/Serie | Science for Systems ; 53 |
| Zusatzinfo | num., mostly col. illus. and tab. |
| Verlagsort | Stuttgart |
| Sprache | englisch |
| Maße | 148 x 210 mm |
| Themenwelt | Technik ► Elektrotechnik / Energietechnik |
| Schlagworte | B • Circuits and components • electronic devices • electronic devices & materials • Electronics engineering • Elektroingenieur • Elektroingenieure • Fraunhofer IAF • Hochfrequenztechnik-Ingenieur • Hochfrequenztechnik-Ingenieure • Microwave technology |
| ISBN-10 | 3-8396-1762-6 / 3839617626 |
| ISBN-13 | 978-3-8396-1762-5 / 9783839617625 |
| Zustand | Neuware |
