Maximum Length Sequences for Radar and Synchronization (eBook)

Sebastian Br& #xFC; ckner (Autor)

eBook Download: PDF

2016 | 1. Auflage
158 Seiten
Cuvillier Verlag
978-3-7369-8192-8 (ISBN)

Infos

This dissertation demonstrates the implementation of ultra-wideband (UWB) radar sensors using commercial off-the-shelf electronics. The sensors are based on the correlation of binary pseudo noise sequences (M-sequences), combining low transmit power requirements with excellent noise and interference suppression. A ranging system is introduced that is able to track moving objects with a standard deviation of 1.73mm at 2m range. Subsequently, a system is developed which can synchronize itself to a reference sequence with 1.96ps RMS jitter. This synchronization system uses an analog correlating control loop (delay lock loop) to achieve tracking of the reference to 0.38% of one chip. The final application shown is a ground penetrating radar (GPR). The system is comprised of three elements: an FPGA, an output driver for the transmitter and a commercial analog-to-digital converter. Comparative measurements on buried pipes and cables prove that this system has achieved detection capability comparable to commercially available pulsed GPRs.

Produkt-Details

• Erscheint lt. Verlag: 29.1.2016
• Sprache: englisch
• Themenwelt: Technik
• ISBN-10: 3-7369-8192-9 / 3736981929
• ISBN-13: 978-3-7369-8192-8 / 9783736981928
