Computing the Environment (eBook)

Digital Design Tools for Simulation and Visualisation of Sustainable Architecture

Brady Peters, Terri Peters (Autoren)

eBook Download: EPUB

2018
John Wiley & Sons (Verlag)
978-1-119-09791-4 (ISBN)

Infos

Computing the Environment presents practical workflows and guidance for designers to get feedback on their design using digital design tools on environmental performance. Starting with an extensive state-of-the-art survey of what top international offices are currently using in their design projects, this book presents detailed descriptions of the tools, algorithms, and workflows used and discusses the theories that underlie these methods. Project examples from Transsolar Klimaengineering, Buro Happold´s SMART Group, Behnish Behnisch Architects, Thomas Herzog, Autodesk Research are contextualized with quotes and references to key thinkers in this field such as Eric Winsberg, Andrew Marsh, Michelle Addington and Ali Malkawi.

Autor

Brady Peters is Assistant Professor in Computational Design at the University of Toronto, Canada. An expert in computational design and architecture, he was Associate Partner in the Specialist Modeling Group at Foster + Partners in London and he holds a Phd in Architecture from the Royal Academy of Fine Arts in Copenhagen. He is one of the Directors of Smartgeometry and regularly lectures internationally at industry and practice-focused events at the intersection of architecture and new technologies. Terri Peters is an architect and researcher with expertise in sustainable design.?She recently completed a PhD in Architecture on the subject in Denmark. Over the past decade, she has published more than 100 texts about sustainable design and new technologies. As a registered architect in the UK, she has worked on ecological design projects. She teaches undergraduate and graduate level courses in sustainable design and holds a Post-Doctoral research position at the University of Toronto.

Inhalt

FOREWORD VI-IX
Phil Bernstein, Yale School of Architecture

1. INTRODUCTION--COMPUTING THE ENVIRONMENT: DESIGN WORKFLOWS FOR THE SIMULATION OF SUSTAINABLE ARCHITECTURE 1-13
Brady Peters and Terri Peters

2. NEW DIALOGUES ABOUT ENERGY: PERFORMANCE, CARBON AND CLIMATE 14-27
Terri Peters

3. PARAMETRIC ENVIRONMENTAL DESIGN: SIMULATION AND GENERATIVE PROCESSES 28-42
Brady Peters

4. DESIGNING ATMOSPHERES: SIMULATING EXPERIENCE 43-57
Brady Peters

5. USE DATA: COMPUTING LIFE-CYCLE AND REAL-TIME VISUALISATION 58-73
Terri Peters

6. NEAR FUTURE DEVELOPMENTS: ADVANCES IN SIMULATION AND REAL-TIME FEEDBACK 74-93
Terri Peters

7. DESIGNING ENVIRONMENTS AND SIMULATING EXPERIENCE: FOSTER + PARTNERS SPECIALIST MODELLING GROUP 94-105
Brady Peters

8. MAXIMISING IMPACT THROUGH PERFORMANCE SIMULATION: THE WORK OF TRANSSOLAR KLIMAENGINEERING 106-117
Terri Peters

9. DESIGNERS NEED FEEDBACK: RESEARCH AND PRACTICE BY KIERANTIMBERLAKE 118-127
Terri Peters

10. ARCHITECTURE SHAPES PERFORMANCE: GXN ADVANCES SOLAR MODELLING AND SENSING 128-137
Terri Peters

11. BESPOKE TOOLS FOR A BETTER WORLD: THE ART OF SUSTAINABLE DESIGN AT BUROHAPPOLD ENGINEERING 138-149
Brady Peters

12. BIG IDEAS: INFORMATION DRIVEN DESIGN 150-162
Brady Peters

13. SIMULATING THE INVISIBLE: MAX FORDHAM DESIGNS LIGHT, AIR AND SOUND 162-175
Terri Peters

14. WHITE ARCHITECTS: BUILD THE FUTURE 176-183
Terri Peters

15. CORE: INTEGRATED COMPUTATION AND RESEARCH 184-191
Terri Peters

16. SUPERSPACE: COMPUTING HUMAN-CENTRIC ARCHITECTURE 192-200
Brady Peters

17. ZHACODE: SKETCHING WITH PERFORMANCE 201-209
Terri Peters

18. WEWORK: BUILDING DATA FOR DESIGN FEEDBACK 210-217
Terri Peters

19. GLOBAL ENVIRONMENTAL CHALLENGES: TECHNOLOGY DESIGN AND ARCHITECTURAL RESPONSES 218-235
Brady Peters and Terri Peters, with contributions from Timur Dogan, Werner Sobek, William W Braham, Kiel Moe, Neil Katz, and Mostapha Sadeghipour Roudsari

INDEX 236-242

Textauszug

1 Earthrise image of Earth, photographed by astronaut Bill Anders during a 1968 Apollo mission, the first manned voyage to orbit the Moon

This photograph is renowned as an influential environmental image, sparking people's impression of Earth as vulnerable and small in a large expansive universe. Looking back on Earth, it seems potentially fragile, a finite, closed-loop system.

1. Introduction—Computing the Environment:
Design Workflows for the Simulation of Sustainable Architecture

BRADY PETERS AND TERRI PETERS

That's here. That's home. That's us. On it everyone you love, everyone you know, everyone you ever heard of, every human being who ever was, lived out their lives. ... There is perhaps no better demonstration of the folly of human conceits than this distant image of our tiny world.(1)

—Carl Sagan

Architects design for the future. The act of drawing is a predictive act of experimenting with possible futures. The buildings architects design today form the cities of the future. Necessary optimists, architects design to achieve better ways of living—turning ‘existing situations into preferred ones'.(2) In architecture, the vast majority of projects are now designed in virtual environments; and, beyond architecture, in almost all sciences, we are seeing the rise of computer simulations as more and more experiments are carried out ‘in silico'.(3) Simulation is a way in which designs can be tested for their future performance. In architecture, ‘while simulation once pertained to modes of presentation, it now connects architecture to the natural sciences and to a methodological and strategic instrument, a tool of knowledge'.(4)

A ‘model' is an approximation of the real world, and following the building of models, simulations are repeated observations of models that enable analysis and visualisation of behaviour.(5) Architects have always used simulations—tools to forecast a range of behaviours in buildings. Yanni Loukissas suggests that this way of working is not new in architecture—Filippo Brunelleschi invented linear perspective to simulate the perception of space, Pierre Patte used ray diagrams to simulate sound and Antoni Gaudí used graphic statics to simulate structural performance. While in today's practice, numerical methods have overtaken graphical techniques in the domains of visualisation, sound and structural performance, what remains constant is the notion of simulation—the desire to get feedback from the design environment.(6)

2 Pierre Patte, acoustic ray-tracing theatre design diagrams, 1782

This drawing of sound paths and their reflections off interior surfaces was used as a way of understanding acoustic performance. This is an early example of performance analysis. Architects have always been interested in this, but digital simulation tools offer more sophisticated and precise options for computing performance, including sound, light and airflow.

Like many architects, Bjarke Ingels designs by imagining a whole new world from scratch. Discussing the work of science fiction author Philip K Dick, Ingels says: ‘the whole story is a narrative pursuit of the potential of the idea or innovation; he writes about what unfolds as a result: problems, conflicts, possibilities, freedoms … it's almost like unleashing a whole new universe based on a single triggering idea'.(7) Ingels describes his design process in a similar way: ‘as soon as I discover some kind of innovation that has altered the game, making the project is like pursuing the consequence of these changes—at that point, I don't have to come up with lots of new ideas; I just have to work with the consequences of a single innovation'.

Simulation is what allows architects to ‘work out the consequences' of their innovations.

Data, Drawing and Simulation

Now these simulations are carried out using computers—and have become part of the (almost) everyday practice of architecture. Simulations transform quantitative models of building physics into qualitative sensory experiences. Internally, these simulations are purely numerical, but through visualisation (and auralisation) can create convincing sensorial events for architects and clients to consider. ‘In sustainable terms, the complexity and inefficiencies of buildings present the most challenging environmental problem. Simulation remains the primary tool for the designer to develop intuitions and analysis of performance,' Azam Khan and Andrew Marsh explain. The software developers say: ‘simulation is about complex relationships and time. Complexity can be defined in many ways, however, put most simply it describes a system in which unspecified emergent behaviour can be observed'.(8)

The digital has been accused of ‘losing its materiality' and it has been said that it ‘edges out the real' by the psychologist Sherry Turkle.(9) However, this book can be seen as an extended argument that the use of computational design tools now enables critically important aspects of environmental performance to become part of the architectural design process; and that through computation designers can better predict what is real and measure the impacts of materials and energies. Aspects of design that were previously impossible or difficult to design for, can now be incorporated into the architectural design process.

3 BIG, Mexico City Villa, 2016, acoustic simulation

This simulation uses Pachyderm, developed by Arthur van der Harten, a plug-in for Rhino that is used for acoustical analysis and simulation. Simulation can be used to understand how material and geometry impact acoustical performance, and this study looks into how the main stair could work as a sound absorber.

Designers are adopting a new generation of accurate and specific simulation tools. Khan and Marsh predicted in 2011: ‘[the] future of simulation lies in three areas: more detailed modelling, building integration and becoming an indispensable part of any design process; that is, simulation as a design tool'(8). Through the use of design simulation, building performance can be predicted. Early geometries can be compared for energy use, daylight, shading, airflow, comfort, sunlight and other parameters. Kjell Anderson writes: ‘simulations provide immediate feedback about the consequences of design decisions, continued use of simulation software validates and hones an individual's intuition'.(10) He further explains that simulation itself can be a highly creative act, it helps designers develop intuitions on real performance, as ‘play leads to understanding'.

Computation in Practice

The contemporary concepts and workflows in Computing the Environment have roots in earlier design experiments and technological advancements, and a path can be traced from early parametric modelling to current advances in custom tool development. In 1963, Ivan Sutherland created the first computer program to design architecture. He created a program that could not only draw geometry, but also create relationships between different elements in the design (associative modelling), and compute basic structural performance analysis.(11) However, when design software was introduced to architectural practice, it only functioned as a virtual drafting board; the important ‘computed' aspects of parametric relationships and performance were not included. Starting in the early 1980s, 2D drafting continued the practice of representing buildings as multiple 2D drawings. 2D drafting technology could be retrofitted to existing design practice, using existing skills without challenging established professional methods and conventions.(12)

Robert Aish sees the history of computer-aided design (CAD) as being divided into three eras: the 2D drafting era, the building information modelling (BIM) era and the design computation era. The BIM era actually started before the 2D drafting era in the 1980s, and is based on the idea that buildings are assemblies of components, but that does not necessarily imply that a designer conceives of a building in terms of such assemblies. This ‘component' assumption forces the designer to think about micro ideas (the components) before macro ideas (the building form). The design computation era introduced the distinction between a generative description of a building and the resulting generated model, and introduced a process where the designer no longer directly models the building, but instead develops an algorithm whose execution generates the model. There are two ways in which this enables a completely different kind of architecture to be created: first, it enables a move away from manual modelling and encourages the adoption of generative design tools; and second, it allows the designer to create his or her own components and, more importantly, to define a building and its components in terms of its behaviour.(12)

A Deeper Way to Think

In the late 1990s, in response to the lack of functionality in available programs, a few architects began to borrow technology from other industries: physics engines in game software, and parametric and fabrication abilities in industrial and aerospace software. Perhaps now we are beginning to re-establish the vision of the original innovators (such as Sutherland), that CAD is not a better way to draw, ‘but a deeper way to think'.(12) Designers are ‘moving away from employing...
