Analysis and Design of Transimpedance Amplifiers for Optical Receivers (eBook)

Eduard Säckinger (Autor)

eBook Download: PDF

2017
John Wiley & Sons (Verlag)
978-1-119-26377-7 (ISBN)

Infos

An up-to-date, comprehensive guide for advanced electrical engineering studentsand electrical engineers working in the IC and optical industries

This book covers the major transimpedance amplifier (TIA) topologies and their circuit implementations for optical receivers. This includes the shunt-feedback TIA, common-base TIA, common-gate TIA, regulated-cascode TIA, distributed-amplifier TIA, nonresistive feedback TIA, current-mode TIA, burst-mode TIA, and analog-receiver TIA. The noise, transimpedance, and other performance parameters of these circuits are analyzed and optimized. Topics of interest include post amplifiers, differential vs. single-ended TIAs, DC input current control, and adaptive transimpedance. The book features real-world examples of TIA circuits for a variety of receivers (direct detection, coherent, burst-mode, etc.) implemented in a broad array of technologies (HBT, BiCMOS, CMOS, etc.).

The book begins with an introduction to optical communication systems, signals, and standards. It then moves on to discussions of optical fiber and photodetectors. This discussion includes p-i-n photodetectors; avalanche photodetectors (APD); optically preamplified detectors; integrated detectors, including detectors for silicon photonics; and detectors for phase-modulated signals, including coherent detectors. This is followed by coverage of the optical receiver at the system level: the relationship between noise, sensitivity, optical signal-to-noise ratio (OSNR), and bit-error rate (BER) is explained; receiver impairments, such as intersymbol interference (ISI), are covered. In addition, the author presents TIA specifications and illustrates them with example values from recent product data sheets. The book also includes:

• Many numerical examples throughout that help make the material more concrete for readers
• Real-world product examples that show the performance of actual IC designs
• Chapter summaries that highlight the key points
• Problems and their solutions for readers who want to practice and deepen their understanding of the material
• Appendices that cover communication signals, eye diagrams, timing jitter, nonlinearity, adaptive equalizers, decision point control, forward error correction (FEC), and second-order low-pass transfer functions

Analysis and Design of Transimpedance Amplifiers for Optical Receivers belongs on the reference shelves of every electrical engineer working in the IC and optical industries. It also can serve as a textbook for upper-level undergraduates and graduate students studying integrated circuit design and optical communication.

EDUARD SÄCKINGER, PhD, is Principal Analog Engineer at MACOM Technology Solutions, USA. For more than ten years, Dr. Säckinger worked at Bell Laboratories (AT&T and Lucent Technologies). After that, he joined Agere Systems (a Lucent spin-off), Conexant Systems, and Ikanos Communications (through an acquisition). He has conducted seminars on broadband circuits for optical fiber communication at Agere Systems, Lucent Technologies, MEAD Microelectronics, and the VLSI Symposium. He served as an Associate Editor for IEEE Journal of Solid-State Circuits for six years. He is the author of the book Broadband Circuits for Optical Fiber Communication.

Inhalt

Cover 1
Title Page 5
Copyright 6
Dedication 7
Contents 9
Preface 13
Chapter 1 Introduction 17
1.1 Optical Transceivers 17
1.2 Modulation Formats 21
1.3 Transmission Modes 28
References 35
Chapter 2 Optical Fibers 39
2.1 Loss and Bandwidth 39
2.2 Dispersion 42
2.3 Nonlinearities 48
2.4 Pulse Spreading due to Chromatic Dispersion 51
2.5 Summary 54
Problems 55
References 56
Chapter 3 Photodetectors 59
3.1 p–i–n Photodetector 59
3.2 Avalanche Photodetector 74
3.3 p–i–n Detector with Optical Preamplifier 81
3.4 Integrated Photodetectors 93
3.5 Detectors for Phase?Modulated Optical Signals 102
3.6 Summary 110
Problems 112
References 113
Chapter 4 Receiver Fundamentals 123
4.1 Receiver Model 123
4.2 Noise and Bit?Error Rate 125
4.3 Signal?to?Noise Ratio 133
4.4 Sensitivity 136
4.5 Noise Bandwidths and Personick Integrals 151
4.6 Optical Signal?to?Noise Ratio 155
4.7 Power Penalty 164
4.8 Intersymbol Interference and Bandwidth 169
4.9 Frequency Response 181
4.10 Summary 186
Problems 188
References 190
Chapter 5 Transimpedance Amplifier Specifications 197
5.1 Transimpedance 197
5.2 Input Overload Current 202
5.3 Maximum Input Current for Linear Operation 203
5.4 Bandwidth 204
5.5 Phase Linearity and Group?Delay Variation 205
5.6 Timing Jitter 206
5.7 Input?Referred Noise Current 207
5.8 Crosstalk 213
5.9 Product Examples 215
5.10 Summary 217
Problems 218
References 218
Chapter 6 Basic Transimpedance Amplifier Design 223
6.1 Low? and High?Impedance Front?Ends 223
6.2 Shunt?Feedback TIA 226
6.3 Noise Analysis 246
6.4 Noise Optimization 258
6.5 Noise Matching 270
6.6 Summary 283
Problems 285
References 288
Chapter 7 Advanced Transimpedance Amplifier Design I 295
7.1 TIA with Post Amplifier 295
7.2 TIA with Differential Inputs and Outputs 300
7.3 TIA with DC Input Current Control 305
7.4 TIA with Adaptive Transimpedance 308
7.5 Common?Base and Common?Gate TIAs 317
7.6 Regulated?Cascode TIA 328
7.7 TIA with Inductive Broadbanding 336
7.8 Distributed?Amplifier TIA 341
7.9 Summary 347
Problems 349
References 350
Chapter 8 Advanced Transimpedance Amplifier Design II 359
8.1 TIA with Nonresistive Feedback 359
8.2 Current?Mode TIA 365
8.3 TIA with Bootstrapped Photodetector 367
8.4 Burst?Mode TIA 368
8.5 Analog Receiver TIA 376
8.6 Summary 380
Problems 381
References 381
Chapter 9 Transimpedance Amplifier Circuit Examples 389
9.1 BJT, HBT, and BiCMOS Circuits 389
9.2 CMOS Circuits 396
9.3 MESFET and HFET Circuits 403
9.4 Summary 405
References 408
Appendix A Communication Signals 413
A.1 Non?Return?to?Zero Signal 413
A.2 Return?to?Zero Signal 417
A.3 Pulse Amplitude?Modulated Signal 419
A.4 Analog Television Signal 422
A.5 Digital Television Signal 424
References 427
Appendix B Eye Diagrams 429
References 436
Appendix C Timing Jitter 437
C.1 Data Jitter 437
C.2 Clock Jitter 447
C.3 Jitter, Phase Noise, and Bit?Error Rate 451
Problems 454
References 454
Appendix D Nonlinearity 457
D.1 Gain Compression 458
D.2 Harmonic Distortions 459
D.3 Intermodulation Distortions 460
D.4 Composite Distortions 462
Problems 465
References 465
Appendix E Adaptive Equalizers 467
E.1 Feedforward and Decision?Feedback Equalizers 468
E.2 Adaptation Algorithms 472
E.3 Hardware Implementations 476
Problems 479
References 479
Appendix F Decision?Point Control 485
Problems 489
References 489
Appendix G Forward Error Correction 491
Problems 497
References 497
Appendix H Second?Order Low?Pass Transfer Functions 499
References 511
Appendix I Answers to the Problems 513
Chapter 2 513
Chapter 3 515
Chapter 4 518
Chapter 5 525
Chapter 6 527
Chapter 7 539
Chapter 8 544
Appendices 547
References 549
Appendix J Notation 553
Appendix K Symbols 555
Latin Symbols 555
Greek Symbols 563
Special Symbols 564
Appendix L Acronyms 565
Index 573
EULA 587

Produkt-Details

• Erscheint lt. Verlag: 26.9.2017
• Sprache: englisch
• Themenwelt: Technik ► Elektrotechnik / Energietechnik
• Schlagworte: active-feedback tias • adaptive transimpedance • analog-receiver tias • and bit-error rate • avalanche photodetectors • burst-mode tias • capacitive-feedback tias • coherent detectors • coherent receivers • common-base tias • common-gate tias • Communication technology • current-mode tias • dc input current control • detectors for phase-modulated signals • detectors for silicon photonics • differential tias • distributed-amplifier tias • Electrical & Electronics Engineering • Elektronischen Rauschen • Elektrotechnik u. Elektronik • feedforward tias • high-frequency integrated circuit design • integrated detectors • Intersymbol Interference • Kommunikationstechnik • Noise Analysis • Noise in Electronic Systems • noise matching • nonlinear distortions • nonresistive feedback tias • Optical Communications • optical communication signals • optical communication standards • optical communication systems • optical-feedback tias • optically preamplified detectors • optical receiver applications • optical receiver circuitry • optical receiver design • optical receiver impairments • optical signal-to-noise ratio • Optische Nachrichtentechnik • p-i-n photodetectors • Post Amplifiers • regulated cascode tias • relationships between noise • Sensitivity • shunt-feedback tias • single-ended tias • TIAs • tia topologies • Timing Jitter • transfer impedance amplifiers • transimpedance amplifier circuit implementations • transimpedance amplifier implementations in broadband communications • transimpedance amplifier implementations in optical communications • transimpedance amplifier product data sheets • Transimpedance amplifiers • transimpedance amplifier specifications • transimpedance amplifier topologies • transimpedance limit
• ISBN-10: 1-119-26377-8 / 1119263778
• ISBN-13: 978-1-119-26377-7 / 9781119263777
