This book integrates the physical processes of dam breaching and the mathematical aspects of risk assessment in a concise manner The first book that introduces the causes, processes and consequences of dam failures Integrates the physical processes of dam breaching and the mathematical aspects of risk assessment in a concise manner Emphasizes integrating theory and practice to better demonstrate the application of risk assessment and decision methodologies to real cases Intends to formulate dam-breaching emergency management steps in a scientific structure

Textauszug

1
Dams and Their Components

1.1 Classification of Dams

A dam is a barrier that impounds water. Dams have been an essential infrastructure in society that contributes to socioeconomic development and prosperity. They are built for a number of purposes, including flood control, irrigation, hydropower, water supply, and recreation. Dams can be classified in many ways, depending on their size, materials, structural types, construction methods, etc. According to the definition of the International Commission on Large Dams (ICOLD, 1998a), a reference dam height for distinguishing large dams from small dams is 15 m. Based on the materials used, dams can be classified as earthfill or rockfill dams, concrete dams, masonry dams, cemented sand and gravel dams, and others. Dams of earthfill or rockfill materials are generally called embankment dams. Based on the structural types adopted, dams can be divided into gravity dams, arch dams, buttress dams, and others. Very often dams are constructed with a combination of two or more structural forms or materials. Of the various types of dam, embankment dams are the most common.

ICOLD (1998) has published a world register of dams, which gives some facts regarding the numbers of different types of dam throughout the world. There are 25,410 dams over 15 m high, of which 12,000 were built for irrigation, 6500 for hydropower and 5500 for water supply, although many of them serve more than one purpose. Embankment dams of earthfill predominate over the others, comprising about 64% of all reported dams, while those of rockfill comprise 8%. Masonry or concrete gravity dams represent 19%, arch dams 4%, and buttress dams 1.4%. Dams lower than 30 m form 62% of the reported dams, while those lower than 60 m comprise 90% and those higher than 100 m just over 2% of the total number of dams.

Topography and geology are the two primary factors in weighing the merits of dam types. These interrelated characteristics of the dam site influence the loading distribution on the foundation and the seepage patterns through the reservoir margins. Embankment dams can be built on a variety of foundations, ranging from weak deposits to strong rocks, which is one of the most important reasons for their wide use in the world. A dam project usually comprises several components, including a water‐retaining structure (e.g. the dam), a water‐releasing structure (e.g. the spillway), a water‐conveying structure (e.g. conduits), and others (e.g. power plants). In addition to the main structure of the dam, there are appurtenant structures such as the spillway, conduit, and power plant around a dam that are necessary for the operation of the whole dam system. Failures of, or accidents involving dams may be attributed to defects in either the dams themselves or their appurtenant structures.

Landslide dams are natural dams caused by rapid deposition of landslides, debris flows, or rockfall materials. The formation of most landslide dams is trigged by rainfall or earthquakes. Earthquake is the most important cause. For instance, the Wenchuan earthquake in 2008 triggered 257 sizable landslide dams. Landslide dams and constructed embankment dams are similar in materials but different in geometry, soil components, and soil parameters. The differences largely influence the failure modes and breaching mechanisms of these two types of dam.

Dikes are a special type of dam. Although the height of a dike is typically small compared with that of a dam, a dike often protects a significant worth of property. Hence the failure statistics and mechanisms of dikes are also introduced in this book.

Here in Chapter 1, the structures of constructed embankment dams, natural landslide dams, concrete gravity dams, concrete arch dams, and dikes are introduced briefly.

1.2 Constructed Embankment Dams

Commonly constructed embankment dams can be divided into homogeneous dams, earth and rockfill dams with cores, and concrete‐faced rockfill dams. A homogeneous dam (Figure 1.1) consists mainly of one single type of material. Such a dam is often constructed for soil and water conservation purposes, and many dams can be constructed along a gully in which soil erosion is serious. A conduit or other type of water passage facility may be installed inside a homogeneous dam. The interface between the conduit and the surrounding soils may easily become a channel of concentrated leak erosion.

Figure 1.1 A homogeneous dam with a conduit

An embankment dam can be constructed with earthfill or rockfill. Any dam which relies on fragmented rock materials as a major structural element is called a rockfill dam (Singh and Varshney, 1995). High quality rockfill is ideal for high‐rise dams because it provides high shear strength and good drainage. A rockfill dam often has a vertical earth core or inclined earth core for seepage control. When a vertical core is adopted, the dam is zoned, with rockfill zones on both sides, a low‐permeability zone (i.e. the earth core) in the middle, and transition and filter zones in between the core and the rockfill zones (Figure 1.2). The filters protect the earth core from internal erosion. They must be much more permeable than the core material and not be clogged by particles migrated from the core. The function of the transition zones is to coordinate the deformations of the core and the rockfill to minimize the stress arch effect and differential settlements.

Figure 1.2 A section of the 314 m high Shuangjiangkou rockfill dam

Figure 1.2 shows a typical section of the Shuangjiangkou dam with a vertical core. Located on the upper reach of the Dadu River in Sichuan, China, the dam is 314 high, one of the highest dams in the world. The overburden at the dam site is relatively shallow (48–57 m) and was excavated so that the vertical core could be constructed on the bedrock.

When the overburden is thick and pervious, cut‐off walls may be required to minimize the seepage through the foundation and seepage‐related problems in the foundation and the abutments. The cut‐off walls for the 186 m high Pubugou rockfill dam are shown in Figure 1.3 as an example. This dam is also situated on the Dadu River in Sichuan, China. The maximum overburden thickness is 78 m. The overburden alluvium materials are gap‐graded, and highly heterogeneous spatially. Hence two concrete cut‐off walls were constructed through the overburden. The connection between the core and the walls was carefully designed to avoid stress concentrations and to alleviate the unfavorable influence of the large differential settlement between the walls and the surrounding soil. A highly plastic clay zone was constructed; one cut‐off wall was embedded in the plastic clay and the other wall was connected to a drainage gallery, which was in turn embedded in the plastic clay.

Figure 1.3 A section of the Pubugou rockfill dam with a vertical earth core

A sloping upstream earth core may be adopted (Figure 1.4) when weather conditions do not allow the construction of a central vertical core all year round. The sloping core and the filters can be placed after the construction of the downstream rockfill. In this way, during staged construction, the rockfill can be placed all year round while the sloping core is placed during the dry season when mixing of the clayey core materials is practical. Figure 1.4 shows a section of the 160 m high Xiaolangdi dam with a sloping core. The bottom width of the core is 102 m and the core is extended to the upstream cofferdam through an impervious blanket. The overburden exceeds 70 m and two concrete cut‐off walls were constructed, one beneath the sloping core and the other beneath the upstream cofferdam.

Figure 1.4 A section of the Xiaolangdi dam with an inclined earth core

The seepage through a rockfill dam can also be controlled by placing an impervious reinforced concrete plate at the upstream face of the dam. Such a dam is termed as a concrete‐faced rockfill dam (CFRD). Figure 1.5 shows a section of the 233 m high Shuibuya CFRD located on the Qingjiang River in Hubei, China. A CRFD consists of the rockfill, the face plate, and transition and filter zones. The rockfill provides free drainage and high shear strength so that the profile of the dam can be smaller than that of a cored dam. The reinforced concrete face plate is cast with longitudinal and transverse joints and waterstops to allow for differential movements of the plate. The transition zone serves as a cushion to support the face plate. When the joints leak or the plate cracks, the transition and filter zones also limit the leakage, and the filter between the transition zone and the rockfill prevents internal erosion at the interface. CFRDs have been the most common type of high rise rockfill dams over the past decade. Since 1985, more than 80 CFRDs higher than 100 m have been constructed or are under construction in China (Jia et al., 2014). However, separation of the face plate from the cushion and extruding rupture of the face plate have occurred in several CFRDs.

Figure 1.5 A section of Shuibuya concrete‐faced rockfill dam

1.3 Landslide Dams

A landslide dam is part of a natural landslide deposit that blocks a river and causes damming of the river. Once the river is...
