Printed Circuits Handbook, Seventh Edition
McGraw-Hill Inc.,US (Verlag)
978-0-07-183395-0 (ISBN)
Publisher's Note: Products purchased from Third Party sellers are not guaranteed by the publisher for quality, authenticity, or access to any online entitlements included with the product.
The Most Complete and Widely Used Guide to Printed Circuits, Now Updated and Thoroughly Revised
The Printed Circuits Handbook has served as the definitive source for coverage of every facet of printed circuit boards and assemblies for 50 years. And now, for the first time anywhere, the new edition of this essential guide provides time-saving tools for success in the area of printed circuit supply chain management, including an entire new section on the elements of design, supplier identification and qualification, process control, product acceptance processes, and quality and reliability specification and assurance. Written by a team of experts from around the world, this encyclopedic resource has been thoroughly revised and expanded to include the latest printed circuit tools and technologies – from design to fabrication. Hundreds of illustrations and charts demonstrate key concepts, and valuable tables provide quick and easy access to essential information.
This new edition of the most trusted guide to printed circuits includes:
Introduction to Printed Circuits
Supply Chain Management
Lead-Free Materials and Processes
Engineering and Design of Printed Circuits
Base Materials for All Applications
Fabrication Processes
High Density Interconnection
Bare Board Testing
Assembly Processes
Soldering Materials and Processes
Non-Solder Interconnection
Quality Specification and Assessment
Reliability Prediction and Assessment
Assembly Testing
Repair and Rework
Flexible Circuits
And Much More
Clyde F. Coombs, Jr, (Los Altos, CA) recently retired from Hewlett-Packard. He is the editor of all five editions of the Printed Circuits Handbook, the first of which was published in 1967. He is also the editor of two editions of the Electronics Instrument Handbook and the communications Network Test and Measurement Handbook.
