Chapter 2

Hot-Carrier Injection Mechanisms

2.1 Introduction

In recent years, since advanced fine-line patterning technologies have made it possible for device miniaturization to approach its physical limits, interest in hot-electron injection and associated device degradation has increased. This is because hot-electron effects impose more severe constraints on very large-scale integration (VLSI) device design as device dimensions are reduced. Main interest has focused on channel hot-electron (CHE) injection. Substrate hot-electron (SHE) injection has also been used to investigate gate insulator qualities. Both of these injection mechanisms are schematically illustrated in Figure 2.1. Ning et al. [1977b] have demonstrated CHE effects extensively, since it is relatively easy to measure the injection gate current (IG) with a 2- or 3-μm Leff metal-oxide-semiconductor field-effect transistor (MOSFET).

Figure 2.1 Schematic diagram of channel hot-electron (CHE) injection and substrate hot-electron (SHE) injection.

However, when accounting for the causes of VLSI circuit degradation, it seems to be necessary for not only CHE but also other injection mechanisms to exist. For example, Fair and Sun [1981] have proposed a hot hole–induced degradation mechanism. In this chapter, not only the above two injections but also two newer hot-carrier injection mechanisms are discussed, both experimentally and theoretically. They are drain avalanche hot-carrier (DAHC) injection and secondarily generated hot-electron (SGHE) injection. Device degradation due to these injections is also clarified by comparing each with that due to CHE injection. Before moving on to hot-carrier injection mechanisms, the physics of hot carriers will be discussed briefly in the next section.

2.2 Avalanche Breakdown

Hot-carrier effects in Si VLSI circuits represent phenomena that are brought about by high-energy carriers created by the channel electric field. These fundamental physical mechanisms share some common characteristics with time-dependent dielectric breakdown (TDDB), radiation damage (RD) due to cosmic and α-rays, and electrostatic discharge (ESD), as shown schematically in Figure 2.2. The commonality lies in the phenomenon of avalanche multiplication. As a background on hot-carrier injection, the avalanche breakdown phenomenon is discussed below.

Figure 2.2 Problems related to hot-carrier effects.

2.2.1 AVALANCHE MULTIPLICATION

The breakdown phenomenon determines the highest applicable voltage and limits the speed and power-handling capacity of discrete MOSFET devices or MOS integrated circuits. Therefore, breakdown voltage is as important as transconductance or threshold voltage in MOS device design. However, there have been few theories which account for the source–drain breakdown voltages of MOSFETs [Grove, 1967] due to the inability to estimate accurately the electric field distribution.

The avalanche breakdown characteristics in MOSFETs are divided into two types. One is normal breakdown observed in p-MOSFETs or long-channel n-MOSFETs. The breakdown voltage, BVDS, decreases with an increase in gate voltage in normal breakdown. The other is negative-resistance breakdown, which is often observed in short-channel n-MOSFETs. The breakdown voltage of p-MOSFETs or long-channel n-MOSFETs increases with increase in gate voltage magnitude, as depicted in Figure 2.3a. However, BVDS decreases with increase in VG, and the sustain voltage, BV′DS apparently exists in the negative-resistance breakdown observed in short-channel n-MOSFETs as depicted in Figure 2.3b.

Figure 2.3 Typical source-drain breakdown characteristics. (a) Normal breakdown in a n-channel MOSFET. (b) Negative-resistance breakdown in an p-channel MOSFET. (Reprinted with permission from T. Toyabe, K. Yamaguchi, S. Asai, and M. S. Mock, “A Numerical Model of Avalanche Breakdown in MOSFETs,” IEEE Trans. Electron Dev. 25, 825–832 (© 1978 IEEE).)

These avalanche breakdown characteristics are caused by the impact ionization of carriers in the high-field region, which develops around the reverse-biased drain-substrate junction. The avalanche breakdown in a planar p–n junction can be analyzed relative easily, since the electric field is known from an analytical solution of Poisson’s equation [Sze, 1969]. The electric field distribution in the drain region of a MOSFET is more complicated because the field is intensified by the presence of the insulated gate.

The two-dimensional analysis reported by Toyabe et al. [1978] shows that carrier leaves the surface at the so-called pinch-off point and flows deep within the substrate before reaching the source, as depicted in Figure 2.4. The electric field is highest just beneath the surface. However, the seed current of avalanche multiplication in this region is the small reverse-biased saturation current, ID0. In addition, the primary channel current, which is the source current, IS, is multiplied by a relatively high electric field. Thus the drain current, ID, can be written by

D=M*IS+MID0.

  (2.1)

Figure 2.4 Cross section of an n-MOSFET showing the current components resulting from avalanche multiplication near the drain. (Reprinted with permission from T. Toyabe, K. Yamaguchi, S. Asai, and M. S. Mock, “A Numerical Model of Avalanche Breakdown in MOSFETs,” IEEE Trans. Electron Dev. 25, 825–832 (© 1978 IEEE).)

The multiplication factors, M and M*, are given by

=1/1−Iion

  (2.2)

and

*=1/1−Iion*,

  (2.3)

where Iion and I*ion are ionization integrals. Iion is obtained as

ion=∫αnexp−∫xαn−αpdx′dx,

  (2.4)

where αn and αp are the ionization rates of electrons and holes, respectively. The integration path is along the channel (in the x-direction). Similarly, I*ion is expressed as

ion*=∫αnexp−∫ζαn−αpdζ′dζ,

  (2.5)

where the integration is carried out along the channel current path represented by a curvilinear coordinate ζ. The channel current path is determined by locating the position of the maximum current density on each vertical grid line and connecting these positions. αn and αp are calculated as functions of the electric field using the expression given by Niehaus et al. [1973].

2.2.2 NORMAL BREAKDOWN

The normal breakdown as depicted in Figure 2.3a shows a current–voltage behavior similar to breakdown characteristics of a reverse-biased p–n junction. The second term on the right-hand side of Eq. (2.1) is responsible for this breakdown. The device is then expected to have normal breakdown when the multiplication factor M becomes infinity. Thus the normal breakdown voltage is the drain voltage which makes the ionization integral, Iion, equal to unity.

2.2.3 NEGATIVE-RESISTANCE BREAKDOWN

The negative-resistance breakdown observed in short-channel n-MOSFETs occurs at a voltage lower than those expected from the normal breakdown voltages of long-channel devices. Therefore, a rapid increase in drain current at breakdown is expected to come from the multiplication of the source current, which is represented by the first term on the right side of Equation (2.1).

The excess substrate current, ISUB, is obtained from Eq. (2.1) as

SUB=ID−IS≅M*−1IS,

  (2.6)

where the term MID0 in Eq. (2.1) is ignored, since M is on the order of unity and ID0 is much smaller than IS. A voltage drop of RsubISUB across the substrate resistance acts as a back bias in the forward direction. This positive back-biasing increases the source current, Is, and, subsequently, ISUB. This increase continues until the substrate–source junction is turned on. Then, a smaller voltage is sufficient to sustain a higher current, resulting in negative resistance.

The potential at the lower boundary of the intrinsic FET is assumed to be constant as shown in Figure 2.4. Thus the back bias (substrate-to-source voltage), VSUB, is given as

SUB=−ISUBRsub+VSUB0,

  (2.7)

where VSUB0 is the external back-bias voltage. From Eqs. (2.6) and...
