Simulation of Large State Variations in Steam Power Plants

Dynamics of Large Scale Systems

Richard Dolezal (Autor)

Buch | Softcover

IX, 110 Seiten

1987
Springer Berlin (Verlag)
978-3-540-18053-1 (ISBN)

Lese- und Medienproben

Inhaltsverzeichnis (PDF)

Artikel merken

The present simulation method has been developed at the Institute for Power Technology and Steam Generation (IVD) of the University of Stuttgart. It is being successfully employed in the analysis of processes involving large state changes such as start-ups, shut downs, malfunctions and failures in steam power generating unit, which is a large scale system consisting of several subsystems with distributed parameters, to which the steam generator also belongs. This research resulted from the increasing use of the once-through boiler, while simultaneously raising the steam parameters into the region of the supercritical state, using sliding pressure operation, combined processes with gas and steam turbines etc. The objective of this system simulation is to reduce losses of heat and condensate and to minimise unavoidable thermal stresses. The project was financed between 1979 and 1983 by the German Research Society (DFG) as part of the special research section Nr. 157 'Thermal power plants'. The Westfalen Power Company Inc. (VEW) sponsored the start-up code 'DYSTAR'. We would like to express our thanks for this support. The following members of the IVD were involved in this research project: Dr.-Ing. J. Kley Dipl.-Ing. G. Riemenschneider Dr.-Ing. A. Rolf Dipl.-Ing. U. Mayer Dipl.-lng. E. Dr.-lng. M. Klug Pfleger Dr.-Ing. G. Berndt Presently it is intended to use this non-linear, time-variant model of a power generating unit with a variable process and system struc ture as the basis for simple code versions, which one can employ e.g.

List of Symbols.- I Non-Linear Time-Variant Model.- 1. Introduction.- 2. The Limitations of Process Simulation Using Linearised, Time-Invariant Differential Equations.- 3. The Dynamic Behaviour of a Two-Flow Heat Exchanger.- 4. The Algorithm of Analytical Approximation.- 5. Change of the Inlet Temperature in an Unheated Pipe as an Example of a Disturbance on the Hot Water Flow Side.- 6. The Decoupled Algorithm.- II Non-Linear, Time-Variant Process Models.- 7. Two Flow Heat Exchanger with a One-Phase Compressible Working Medium Flow.- 8. Two-Phase Flow of the Working Medium.- 9. The Direction of the Propagation of a Disturbance in a Boiler.- 10. Model of the Steam Generator and the Power Generating Unit.- III Power Generating Unit and Large State Variations.- 11. Power Generating Unit Model.- 12. Starting-Up Process Model.- 13. Malfunctions and Failures.- References.

Erscheint lt. Verlag	31.7.1987
Reihe/Serie	Lecture Notes in Engineering
Zusatzinfo	IX, 110 p.
Verlagsort	Berlin
Sprache	englisch
Maße	170 x 244 mm
Gewicht	235 g
Themenwelt	Naturwissenschaften ► Physik / Astronomie ► Thermodynamik
Themenwelt	Technik ► Elektrotechnik / Energietechnik
Schlagworte	algorithms • Behavior • Development • differential equation • Dynamics • Heat • Phase • Plant • plants • Simulation • System • Temperature • Two-phase flow • Water
ISBN-10	3-540-18053-2 / 3540180532
ISBN-13	978-3-540-18053-1 / 9783540180531
