Nano and Micromachining

J. Paulo Davim, Mark J. Jackson (Herausgeber)

Buch | Hardcover

212 Seiten

2008
ISTE Ltd and John Wiley & Sons Inc (Verlag)
978-1-84821-103-2 (ISBN)

Titel z.Zt. nicht lieferbar
Versandkostenfrei
Auch auf Rechnung

Artikel merken

This book provides the fundamentals and recent advances in nano and micromachining for modern manufacturing engineering. It begins by outlining nanomachining before discussing various advances in field and machining processes.

This book provides the fundamentals and recent advances in nano and micromachining for modern manufacturing engineering. It begins by providing an outline of nanomachining with emphasis being given to molecular dynamics, cutting, and chip formation, before discussing various advances in field and machining processes, including advances in diamond cutting tools, conventional processes (microturning, microdrilling, micromilling, etc.), grinding and ultra-precision processes, and non-conventional machining processes (laser micromachining, EDM micromachining, etc.).

The coverage concludes with an evaluation of subsurface damages in nano and micromachining and a presentation of applications in industry. As such, not only is this book useful to those studying engineering or machining at both an undergraduate and postgraduate level, but it also serves as a useful reference guide for academics and engineers involved in these areas and related industries.

J. Paul Davim works for KINNSYS, Brussels, Belgium. Mark Jackson works for Jackson Ashcroft Associates, London, UK.
