EM Detection of Concealed Targets (eBook)
304 Seiten
Wiley (Verlag)
978-0-470-53981-1 (ISBN)
DAVID J. DANIELS, BSC, MSC, CENG, FIET, SMIEE, is the Chief Consultant for Sensors at Cobham Technical Services (formerly known as ERA Technology). David has more than thirty years of experience in the development of radar, acoustic, and electromagnetic systems as well as products for security, sensing, and test applications for the military and commercial enterprises. He has brought such products to market as acoustic detection systems, fiber optic cryogenic liquid leak sensors, marine radar rescue transponders, ultra-wideband microwave amplifiers, ground-penetrating radar, land-mine detectors, and RF and microwave security systems. His current interests center on sensor systems for land-mine detection, homeland security, and military counterterrorist activities.
Preface.
Acknowledgments.
List of Frequently used Acronyms.
1 Introduction.
1.1 Scope and Objectives.
1.2 Structure.
1.3 Market Needs for Security.
1.4 Targets inside Containers.
1.5 Buried Land Mines.
1.6 Forensic Detection of Buried Bodies.
1.7 Avalanche and Earthquake Victims.
1.8 Concealed Humans.
1.9 Concealed Targets on Humans.
1.10 Radiological Considerations.
1.11 Licensing Considerations.
1.12 Statistics of the Detection Performance of a Sensor.
1.13 Summary.
2 Physics of Propagation.
2.1 Introduction.
2.2 Propagation of Electromagnetic Fields in Free Space.
2.2.1 Reactive Fields.
2.2.2 Near Fields.
2.2.3 Far Fields.
2.2.4 Polarization.
2.2.5 Radar Cross Section.
2.2.6 Reflection.
2.2.7 Refraction.
2.2.8 Brewster Angle.
2.2.9 Dispersion.
2.2.10 Anisotropy.
2.2.11 Clutter.
2.3 Propagation of Energy in a Dielectric.
2.3.1 Introduction.
2.3.2 Velocity in a Dielectric.
2.3.3 Impedance of a Dielectric.
2.3.4 Propagation Loss in a Dielectric.
2.3.5 Coupling Losses into Materials.
2.4 Dielectric Properties of Soils and Rocks.
2.5 Propagation in Water.
2.6 Atmospheric Absorption of Electromagnetic Waves.
2.6.1 Rain and Fog.
2.6.2 Dust, Smoke, and Sand Storms.
2.7 Attenuation of Electromagnetic Fields by Materials.
2.7.1 Human and Animal.
2.7.2 Heartbeat.
2.7.3 Respiration.
2.7.4 Clothing.
2.7.5 Construction Materials.
2.7.6 Explosives.
2.8 Summary.
3 Antennas.
3.1 Introduction.
3.2 Antenna Parameters.
3.2.1 Antenna Directivity.
3.2.2 Antenna Gain.
3.2.3 Antenna Efficiency.
3.2.4 Side Lobes and Back Lobes.
3.2.5 Bandwidth.
3.2.6 Polarization--Linear, Elliptical, and Circular.
3.2.7 Antenna Phase Center.
3.2.8 Antenna Patterns.
3.2.9 Time Side Lobes and Ring-down.
3.2.10 Antenna Footprint.
3.3 Aperture Antennas.
3.4 Antennas for Proximal Operation.
3.4.1 Introduction.
3.4.2 Coupling Energy into the Ground or a Dielectric.
3.5 Linear Phase Antennas.
3.5.1 Dipoles.
3.5.2 Loaded Antennas.
3.5.3 BiConical Antennas.
3.5.4 Bow-Tie Antennas.
3.5.5 Dielectric Road Antennas.
3.5.6 TEM Horn Antennas.
3.5.7 Impulse Radiating Antennas.
3.6 Nonlinear Phase Antennas.
3.6.1 Vivaldi Antennas.
3.6.2 Equiangular Antennas.
3.6.3 Horn Antennas.
3.7 Antenna Arrays.
3.8 Summary.
4 Nuclear Quadrupole Resonance.
4.1 Introduction.
4.2 Pulse Sequences.
4.3 System Design.
4.3.1 Introduction.
4.3.2 Transmit-and-Receive Coils.
4.3.3 Receiver and Coil Considerations.
4.4 Signal Processing.
4.5 Detection of Explosives.
4.6 Land-Mine Detection.
4.7 Illicit Drugs.
4.7.1 Cocaine.
4.7.2 Cocaine Hydrochloride.
4.7.3 Heroin (Diamorphine).
4.8 Summary.
5 Radar Systems.
5.1 Introduction.
5.2 Doppler Radar Systems.
5.3 Frequency-Domain Radars.
5.3.1 Introduction.
5.3.2 Two-Frequency Doppler Radar.
5.3.3 Stepped Frequency Radar Systems.
5.3.4 Frequency-Modulated Continuous-Wave Radar.
5.4 Harmonic Radar.
5.5 Noise Radar.
5.6 Spatial Modulation.
5.7 Amplitude Modulation.
5.8 Summary.
6 Passive Systems.
6.1 Introduction.
6.2 Principles of Radiometry.
6.3 Total Power Radiometer.
6.4 Dicke Radiometer.
6.5 Minimum Detectable Temperature.
6.6 Temperature Resolution.
6.7 Imaging Systems.
6.8 Summary.
7 Applications and Technology.
7.1 Introduction.
7.2 Physiological Monitoring.
7.3 Earthquake and Avalanche Radar Systems.
7.4 Forensic Applications.
7.5 Through-Wall Radar (TWR) for Surveillance.
7.6 Harmonic Radar Systems.
7.7 Land-Mine Detection Radar Systems.
7.7.1 Handheld Land-Mine Detection Radar Systems.
7.7.2 Vehicle-Mounted Land-Mine Detection Radar Systems.
7.8 Radar for General Search Operations.
7.9 Spatially Modulated Systems.
7.10 Millimeter-Wave Radar Systems.
7.11 Summary.
8 Summary.
References.
Index.
Erscheint lt. Verlag | 3.12.2009 |
---|---|
Reihe/Serie | Wiley Series in Microwave and Optical Engineering |
Sprache | englisch |
Themenwelt | Technik ► Elektrotechnik / Energietechnik |
Technik ► Nachrichtentechnik | |
Schlagworte | Bildgebende Systeme u. Verfahren • Electrical & Electronics Engineering • Elektrotechnik u. Elektronik • Hochfrequenztechnik • Imaging Systems & Technology • Mikrowellen- u. Hochfrequenztechnik u. Theorie • RF / Microwave Theory & Techniques • Signal Processing • Signalverarbeitung |
ISBN-10 | 0-470-53981-X / 047053981X |
ISBN-13 | 978-0-470-53981-1 / 9780470539811 |
