Isogeometric Analysis (eBook)

Toward Integration of CAD and FEA

Yuri Bazilevs, J. Austin Cottrell, Thomas J. R Hughes (Autoren)

eBook Download: PDF

2009 | 1. Auflage
360 Seiten
Wiley (Verlag)
978-0-470-74909-8 (ISBN)

Infos

'The authors are the originators of isogeometric analysis, are excellent scientists and good educators. It is very original. There is no other book on this topic.'
-René de Borst, Eindhoven University of Technology

Written by leading experts in the field and featuring fully integrated colour throughout, Isogeometric Analysis provides a groundbreaking solution for the integration of CAD and FEA technologies. Tom Hughes and his researchers, Austin Cottrell and Yuri Bazilevs, present their pioneering isogeometric approach, which aims to integrate the two techniques of CAD and FEA using precise NURBS geometry in the FEA application. This technology offers the potential to revolutionise automobile, ship and airplane design and analysis by allowing models to be designed, tested and adjusted in one integrative stage.

Providing a systematic approach to the topic, the authors begin with a tutorial introducing the foundations of Isogeometric Analysis, before advancing to a comprehensive coverage of the most recent developments in the technique. The authors offer a clear explanation as to how to add isogeometric capabilities to existing finite element computer programs, demonstrating how to implement and use the technology. Detailed programming examples and datasets are included to impart a thorough knowledge and understanding of the material.

• Provides examples of different applications, showing the reader how to implement isogeometric models
• Addresses readers on both sides of the CAD/FEA divide
• Describes Non-Uniform Rational B-Splines (NURBS) basis functions

J. Austin Cottrell, Thomas J. R. Hughes & Yuri Basilievs, University of Texas at Austin, USA
J. Austin Cottrell is a postdoctoral scholar at the University of Texas at Austin, having received his PhD in Computational and Applied Mathematics in 2007. Isogeometric analysis is a topic pioneered by his graduate research under the supervision of Tom Hughes.

Tom Hughes was a leading professor of mechanical engineering at Stanford University before being lured to join the University of Texas at Austin in 2002 as Professor of Aerospace Engineering and Engineering Mechanics within the Institute for Computational Engineering and Sciences. He is co-editor of the International Journal of Computer Methods in Applied Mechanics and Engineering, a founder and past President of USACM and IACM, and past Chairman of the Applied Mechanics Division of ASME. A world leader in the development of the finite element method, he has received the Walter L. Huber Civil Engineering Research Prize from ASCE, the Melville Medal from ASME, the Computational Mechanics Award from the Japan Society of Mechanical Engineers, the von Neumann Medal from USACM, the Gauss-Newton Medal from IACM, and the Worcester Reed Warner Medal from ASME. Dr. Hughes is a member of the National Academy of Engineering.

Yuri Basilievs also obtained his PhD from the University of Texas at Austin in 2007 under the supervision of Tom Hughes.

---

The authors are the originators of isogeometric analysis, are excellent scientists and good educators. It is very original. There is no other book on this topic. Ren de Borst, Eindhoven University of Technology Written by leading experts in the field and featuring fully integrated colour throughout, Isogeometric Analysis provides a groundbreaking solution for the integration of CAD and FEA technologies. Tom Hughes and his researchers, Austin Cottrell and Yuri Bazilevs, present their pioneering isogeometric approach, which aims to integrate the two techniques of CAD and FEA using precise NURBS geometry in the FEA application. This technology offers the potential to revolutionise automobile, ship and airplane design and analysis by allowing models to be designed, tested and adjusted in one integrative stage. Providing a systematic approach to the topic, the authors begin with a tutorial introducing the foundations of Isogeometric Analysis, before advancing to a comprehensive coverage of the most recent developments in the technique. The authors offer a clear explanation as to how to add isogeometric capabilities to existing finite element computer programs, demonstrating how to implement and use the technology. Detailed programming examples and datasets are included to impart a thorough knowledge and understanding of the material. Provides examples of different applications, showing the reader how to implement isogeometric models Addresses readers on both sides of the CAD/FEA divide Describes Non-Uniform Rational B-Splines (NURBS) basis functions
